84131 AZ EB Floating Probe DO Meter

The AZ 84131 Floating Probe DO Meter is developed under high-quality manufacturing processes to ensure reliability and safety:
ISO 9001 Facility: Manufactured in an ISO 9001 certified environment.
CE EN 61326-1 & IEC 61000: Designed and tested to meet European EMC safety standards.
RoHS & REACH Compliant: We provide a Manufacturer’s Self Declaration, ensuring the product meets environmental safety standards for hazardous substances.

84131 AZ Dissolved Oxygen Device features:
* Big LCD with D.O. & Temperature display
* 100% D.O. calibration in air. Chemical is not required
* Easy replaceable thin membrane kit with high sensitivity
* Refill electrolyte quickly. Simple to maintain
* Selectable % and mg/L unit for D.O. Value
* °C/°F automatic temperature compensation built-in
* Manual salinity and barometric pressure compensation
* Environment green re-chargeable battery via type C port
* Brightness adjustable backlight for dark places

Application of 84131 AZ Dissolved Oxygen Pen:
The portable 84131 AZ DO meter can measure the dissolved oxygen level in water with unit of mg/l in liquid. And the 84131 AZ DO meter would be useful in a variety of applications where it is important to monitor dissolved oxygen levels in water.

1. Aquaculture:
Measuring dissolved oxygen value in water is critical in aquaculture operations to ensure that the fish or other aquatic organisms are getting enough oxygen to survive. 84131 AZ DO PEN can be used to measure the oxygen levels in fish tanks, ponds, or other aquatic environments.

2. Water treatment:
Dissolved oxygen levels are important in the water treatment process, particularly in the biological treatment of wastewater. 84131 AZ Dissolved Oxygen Pen with Floating Probe can be used to measure oxygen levels in aeration tanks and other treatment processes.

3. Environmental monitoring:
Dissolved oxygen value is an important indicator of water quality and can be used to assess the health of aquatic ecosystems. 84131 AZ Dissolved Oxygen Pen can be used to monitor dissolved oxygen levels in lakes, rivers, and other bodies of water.

4. Research:
Dissolved oxygen value can be an important parameter in scientific research, particularly in studies of aquatic organisms and ecosystems. 84131 AZ Dissolved Oxygen Pen can be used by researchers to measure oxygen levels in laboratory experiments or in the field.

The 84131 AZ Dissolved Oxygen Pen was being designed and manufactured by AZ Instrument, a well experienced manufacturer for Environmental Measuring Instrument.

Model	84131
DO Measuring Range	0.0~199.9 (in %)
DO Accuracy	±3% F.S (in %)
DO Resolution	0.1% (in %)
DO Measuring Range	0.00~20.00 (in mg/l)
DO Accuracy	±0.4 (in mg/l)
DO Resolution	0.01 (in mg/l)
Temp. Measuring Range	0~50.0℃, 32~122°F
Temperature Accuracy	±0.5℃, 0.9°F
Temperature Resolution	0.1℃
Manual Compensation	Included
Salinity Adjustable Range	0.0~45.0 ppt
Salinity Resolution	0.1 ppt
Barometric Pressure Adjustable Range	500~760 mmHg/101.3~66.7 Kpa
Barometric Pressure Resolution	1 mmHg/0.1 Kpa
Auto Temp. Compensation	10~40.0℃ 50~104°F
LCD Size	30(L) * 18 (W) mm
Operating Temperature	0~40℃
Operating RH%	Humidity ＜85%
Storage Temperature	0~40℃
Storage RH%	Humidity ＜80%
Sensor Response Time	＜30 seconds for DO, <90 seconds for Temp.
Sensor Warmup time	＜60 seconds after power up
Sensor Life Time	>6 months (with good maintenance)
Meter Size	176(L) * 39(W) * 39(H) mm
Weight	~265g
Battery	3.7V@500mAh re-chargeable battery
Power Consumption	60 hours operation (no backlight condition)
Re-charging Time	1.5 hours
Standard Package	Meter (with battery built-in), Dissolve Oxygen (D.O.) Probe, Electrolyte, 2PCS membrane kits, USB-type C charging cable, Manual, Carry Case
